Setup & Assembly Guide
Thank you for choosing LYKYN. Follow these steps to set up your grow chamber for the first time.
Thank you for choosing LYKYN. Follow these steps to set up your grow chamber for the first time.
Before You Begin
- Open the package carefully and confirm all parts are included.
- Assemble on a smooth, flat surface.
- No tools required.
What's Included
- 1 × Grow Chamber Base
- 4 × Chamber Brackets
- 4 × Side Panels
- 1 × Top Panel
- LED Light Bar (with cable)
- Power Cable (USB-C)
- Quick Start Card
1 Unpack
Remove all contents from the box and verify the items above.
2 Prepare the Brackets
Check that each bracket is pre-assembled.
If any came apart during shipping, align the three protruding lines with the matching holes and press firmly until they lock.
3 Insert the Brackets
Place one bracket in each corner of the base. They should stand straight up to form four vertical supports.
4 Install the Side Panels
Remove protective film.
Identify the "UP" side on each panel.
Slide each panel into the grooves between the brackets.
Ensure panels are fully seated so their tops are level with the bracket edges.
5 Attach the Top Panel
Position the top panel over the brackets.
Start at one corner and press to lock in place.
Working from that corner, move around the perimeter, locking small sections until the top is fully secure.
6 Connect Power & Lighting
Locate the two USB ports on the side:
Use the included cables.
7 Download the LYKYN App
Get LYKYN from the Apple App Store or Google Play.
Follow the in-app steps to pair your chamber.
You're Done
Your LYKYN Grow Chamber is ready. Start your first grow in the app and let the system handle the environment.
