Setup & Assembly Guide

Thank you for choosing LYKYN. Follow these steps to set up your grow chamber for the first time.

Thank you for choosing LYKYN. Follow these steps to set up your grow chamber for the first time.

Before You Begin

  • Open the package carefully and confirm all parts are included.
  • Assemble on a smooth, flat surface.
  • No tools required.

What's Included

  • 1 × Grow Chamber Base
  • 4 × Chamber Brackets
  • 4 × Side Panels
  • 1 × Top Panel
  • LED Light Bar (with cable)
  • Power Cable (USB-C)
  • Quick Start Card

1 Unpack

Remove all contents from the box and verify the items above.

2 Prepare the Brackets

Check that each bracket is pre-assembled.

If any came apart during shipping, align the three protruding lines with the matching holes and press firmly until they lock.

3 Insert the Brackets

Place one bracket in each corner of the base. They should stand straight up to form four vertical supports.

4 Install the Side Panels

Remove protective film.

Identify the "UP" side on each panel.

Slide each panel into the grooves between the brackets.

Ensure panels are fully seated so their tops are level with the bracket edges.

5 Attach the Top Panel

This step can be snug—patience helps.

Position the top panel over the brackets.

Start at one corner and press to lock in place.

Working from that corner, move around the perimeter, locking small sections until the top is fully secure.

6 Connect Power & Lighting

Locate the two USB ports on the side:

USB-A (left)
connects to the LED light
USB-C (right)
connects to power

Use the included cables.

Note: A USB-A power adapter block is not included. Any standard USB-A power adapter will work.

7 Download the LYKYN App

Get LYKYN from the Apple App Store or Google Play.

Follow the in-app steps to pair your chamber.

You're Done

Your LYKYN Grow Chamber is ready. Start your first grow in the app and let the system handle the environment.
